DIN 933 - Hexagon Head Screws Fully Threaded Specifications

DIN 933 - Hexagon Head Screws Fully Threaded Specifications

DIN 933 - Hexagon Head Screws Fully Threaded Specifications


*All measurements in millimeters (mm)*

d1 k e s
M3 2 6 6
M4 3 7.7 7
M5 4 8.8 8
M6 4 11 10
M8 5 14 13
M10 6 19 17
M12 8 21 19
M14 9 24 22
M16 10 27 24
M18 12 30 27
M20 13 34 30
M22 14 36 32
M24 15 40 36
M27 17 45 41
M30 19 51 46
M33 21 55 50
M36 23 61 55
M42 26 71 65
M48 30 83 75

All information is strictly informative

MATRIAL : STAINLESS STEEL 304,304L, 316, 316L, 316TI, 317L, 309, 310, 904L, MONAL K-400, MONAL K-500, INCONAL -600, INCONAL-800, ALLY -625, ALLOY-825, SUS-630, UB-6,B8,B7,TITANIUM, HAST-ALLOY, ALLOY-20
